Not sure if posted already? NASA/Brainchip (working together! )
25 May 2022 — Numem proposes in Phase-I to create a interface system with MRAM which can connect with AKIDA Neuromorphic Processor from
Brainchip to ...
Proposal Information
Proposal Number:
22-1- H6.22-2237
Subtopic Title:
Deep Neural Net and Neuromorphic Processors for In-Space Autonomy and Cognition
Proposal Title:
Neuromorphic Processor with radiation tolerant MRAM
Small Business Concern
Firm:
Numem Inc
Address:
440 N Wolfe Road, Sunnyvale, CA 94085
Phone:
(408) 836-8795
Principal Investigator:
Name:
Nilesh Gharia
E-mail:
ngharia@numem.com
Address:
440 N Wolfe Road, CA 94085 - 3869
Phone:
(408) 836-8795
Business Official:
Name:
Nilesh Gharia
E-mail:
ngharia@numem.com
Address:
440 N Wolfe Road, CA 94085 - 3869
Phone:
(408) 836-8795
Summary Details:
Estimated Technology Readiness Level (TRL) :
Begin: 4
End: 6
Technical Abstract (Limit 2000 characters, approximately 200 words):
Space missions require high-performance, reliable computing platforms and can function in challenging environments. The von Neumann bottleneck constrains performance due to the time and energy consumed during the required data exchange between main memory chip sets and the processor. Neuromorphic computing could emerge as a game changer for space applications where mission success relies on fast and autonomous analysis of a vast array of incoming information from multiple sources.
The future space applications will drive the need for
- Reduced size, weight, and power constrains
- Data retention
- On-board adaptive learning capability
- Autonomous, onboard, and fast data analysis
Neuromorphic processors aligns with the above capabilities. Neuromorphic architectures are inherently fault tolerant, and several hardware implementations have high-radiation tolerance. In addition, neuromorphic algorithms are well-suited to classes of problems of interest to the space community.
Present Neuromorphic solutions for Space applications require FLASH memory for boot and weight storage in case of power loss or intermittent power failures. The FLASH memory has limitations on speed and life-time is limited by about 1M cycles of memory operations due to its endurance. For Deep Space Missions where continuous learning is required with updates on the non-volatile memory, a robust radiation tolerant memory with SRAM like performance but still with non volatility and high endurance is required. MRAM which offers 2.5X to 3.5X density advantage over SRAM, 1000X better endurance over FLASH, high radiation tolerance above 100Krad to 1Mrad and ultra-low power standby leakage which is critical for long battery life between solar recharge is a big advantage for these critical SPACE missions.
Numem proposes in Phase-I to create a interface system with MRAM which can connect with AKIDA Neuromorphic Processor from Brainchip to either limit or replace FLASH operations with MRAM.
Potential NASA Applications (Limit 1500 characters, approximately 150 words):
Object Identification and Change Detection - Neuromorphic Computing could enable more efficient on-orbit data processing and storage
Autonomous Control - As activities in space become more remote and automated, without a human in the loop, this advantage could improve the satellite’s ability to analyze onboard sensor data with better autonomous decisions.
Cybersecurity - Neuromorphic Computing onboard a spacecraft would provide a trusted protection mechanism
It can resolve a fundamental time-energy problem with fast low cost results.
Potential Non-NASA Applications (Limit 1500 characters, approximately 150 words):
Artificial Intellligence applied at Edge for ultra low power IOT applications,Large Scale Operations & Product Customization with vast amount of data-sets,Medicine and Drug discovery for faster analysis and iterations,Imaging & Vision Sensors for classification and detection, Autonomous Operations in Drones and Cars, Robotics Technologies,Defense - Hypersonic and Ballistic Missile Technologies
