Cheers.
Is intriguing as you say though appears one thought last year was already to aim for 22nm and indicated AKD500 might be the implementation
Obviously mentioned 90nm as well which would tie in with NASA as you point out.
Startup BrainChip Inc. has a road-map of larger and smaller SoC exemplars of its Akida spiking neural networking processing architecture and could go to fully-depleted silicon on insulator (FDSOI).
www.eenewseurope.com
Anil Mankar, chief development officer, told eeNews Europe: “Chip production volume is just starting now. But you will see a lot of IP licensing going forward.” He added: “We are process agnostic.”
The near-term focus is supplying the Akida IP to 22nm although some customers may go back to 90nm process, Akida executives said.
Rob Telson, vice president of worldwide sales, said BrainChip is drawing up plans for smaller and larger versions of Akida under the names Akida500, Akida1500 and Akida2000. Some of these may well comply to a new generation of the Akida architecture – Akida 2.0 – due to arrive in 2022.
It is thought Akida500 could be implemented in 22nm FDSOI manufacturing process, and serve as a demonstrator of the agnostic nature of the Akida architecture.
