TATA have developed what they call a reservoir-based spiking NN:
US2023334300A1 METHODS AND SYSTEMS FOR TIME-SERIES CLASSIFICATION USING RESERVOIR-BASED SPIKING NEURAL NETWORK 20220418
The present disclosure relates to methods and systems for time-series classification using a reservoir-based spiking neural network, that can be used at edge computing applications. Conventional reservoir based SNN techniques addressed either by using non-bio-plausible backpropagation-based mechanisms, or by optimizing the network weight parameters. The present disclosure solves the technical problems of TSC, using a reservoir-based spiking neural network. According to the present disclosure, the time-series data is encoded first using a spiking encoder. Then the spiking reservoir is used to extract the spatio-temporal features for the time-series data. Lastly, the extracted spatio-temporal features of the time-series data is used to train a classifier to obtain the time-series classification model that is used to classify the time-series data in real-time, received from edge devices present at the edge computing network.
To my untutored eye, it does look as if it works on a different principle from Akida, but it mat just be LSTM in drag.
However, they do use it in some applications in conjunction with a more conventional SNN:
US2024176987A1 METHOD AND SYSTEM OF SPIKING NEURAL NETWORK-BASED ECG 20221125
This disclosure relates generally to method and system for spiking neural network based ECG classifier for wearable edge devices. Employing deep neural networks to extract the features from ECG signal have high computational intensity and large power consumption. The spiking neural network of the present disclosure obtains a training dataset comprising a plurality of ECG time-series data. The spiking neural network comprise a reservoir-based spiking neural network and a feed forward based spiking neural network. Each of the spiking neural network having a logistic regression-based ECG classifier are trained to classify one or more class labels. The peak-based spike encoder of each spiking neural network obtains a plurality of encoded spike trains from the plurality of ECG time-series. The peak-based spike encoder provides high performance for classifying one or more labels. Efficacy of the peak-based spike encoder for classification is experimentally evaluated with different datasets.
[0037] The SNN layer 304 obtains neuronal trace values of a plurality of feed forward neurons from the plurality of encoded spike trains. Further, a second set of spatio-temporal features are extracted based on the neuronal trace values of the plurality of feed forward neurons for each ECG time-series data from each feed-forward neuron.
The patents refer to ''spatio-temporal features" which is a TENNs speciality, but the TATA patents are a bit early for TENNs, but who knows what goes on behind closed doors?
Last edited:
Boab
I wish I could paint like Vincent
From the article. Apparently we may have to wait another couple of years??View attachment 73151
Creating Futuristic Edge Systems with Neuromorphic Computing
As AI techniques on classical processor architecture become a concern, explore neuromorphic computing to create futuristic systems with intelligence at the edge.www.tcs.com
Other processors that are likely to come out within the next couple of years, such as Zeroth, Akida etc., cater to edge applications.
7für7
Top 20
You know son… We’ve been waiting for so many years already… a year or two more won’t exactly break the record! Right?? Greetings from Thailand
Frangipani
Regular
The Fraunhofer HHI Wireless Communications & Networks Team will be presenting a remote live demo of their neuromorphic wireless cognition PoC (the one using a COTS Spot robot dog, developed as a 6G-Research and Innovation Cluster project and funded by the BMBF / German Federal Ministry of Education and Research) at the upcoming IEEE Global Communications Conference in Cape Town, South Africa (8 - 12 December 2024):
Frontgrade Gaisler on LinkedIn: #spacecomputing
We have launched our latest radiation-hardened microcontroller, the GR716B. Building on the success of the GR716A, this latest innovation is a step forward in…
Frontgrade Gaisler Unveils GR716B, a New Standard in Space-Grade Microcontrollers | Frontgrade
Frontgrade Gaisler has launched its latest radiation-hardened microcontroller, the GR716B. Building on the success of the GR716A, this latest innovation is a step forward in the development of energy-efficient and adaptable microcontrollers for space applications.
Attachments
Last edited:
The Author must not be aware that BRN is currently in talks on many AKIDA engagements and that there is plenty of current interest in TENN's and PICO.
Tomorrow is within the next couple of years, or, for the pessimists, 1 January 2025.
Humble Genius
Regular
Any link to our Brainchip? Puzzling.....
www.linkedin.com
George Kenwright on LinkedIn: Had a great time consulting on the AI-generated VFX for 'Brainchip', a…
Had a great time consulting on the AI-generated VFX for 'Brainchip', a short film from Asparagus Productions. It's going to be 'mind-blowing'... 🤯 with…
Frangipani
Regular
Any link to our Brainchip? Puzzling.....
View attachment 73173
George Kenwright on LinkedIn: Had a great time consulting on the AI-generated VFX for 'Brainchip', a…
Had a great time consulting on the AI-generated VFX for 'Brainchip', a short film from Asparagus Productions. It's going to be 'mind-blowing'... 🤯 with…
Donate to Brain Chip Short Film, organized by Asparagus Productions
Hi, we're Asparagus Productions, and we're fundraising for our next short film, Brain Chip… Asparagus Productions needs your support for Brain Chip Short Film
Frangipani
Regular
View attachment 73151
Creating Futuristic Edge Systems with Neuromorphic Computing
As AI techniques on classical processor architecture become a concern, explore neuromorphic computing to create futuristic systems with intelligence at the edge.
The thing is - while the TCS LinkedIn post is from today, the white paper it links to titled “Advancing edge computing capabilities with neuromorphic platforms” has actually been online since at least 29 November 2022.
That puts the authors’ outlook somewhat into perspective…
I wish they’d always add the date of publication when posting such white papers.
Wayback Machine
Last edited:
Good pick up. That means we are on course and can relax.The thing is - while the TCS LinkedIn post is from today, the white paper it links to titled “Advancing edge computing capabilities with neuromorphic platforms” has actually been online since at least 29 November 2022.
That puts the authors’ outlook somewhat into perspective…
I wish they’d always add the date of publication when posting such white papers.
Wayback Machine
web.archive.org
View attachment 73177
View attachment 73178
Frangipani
Regular
Maximas gratias tibi agimus, Max Maxfield!
www.eejournal.com
November 21, 2024
Earlier this year, I penned a couple of columns under the umbrella title “Mind-Boggling Neuromorphic Brain Chips.” One of the first comments I received concerning these columns was short, sharp, and sweet, simply reading, “Also, Brain-Boggling.”
Arrrggghhh. How did I miss that? How could I not have used “Brain-Boggling Neuromorphic Brain Chips”? There was much gnashing of teeth and rending of garb that day, let me tell you.
The articles in question (see Part 1 and Part 2) were focused on the folks at brainchip, whose claim to fame is to be the world’s first commercial producer of neuromorphic IP.
Before we plunge headfirst into the fray with gusto and abandon (and aplomb, of course), let’s first remind ourselves as to what we mean by the “neuromorphic” moniker. Also, as part of setting the scene, let’s remind ourselves that we are focusing our attentions on implementing artificial intelligence (AI) and machine learning (ML) tasks at the extreme edge of the internet. For example, creating intelligent sensors at the point where the “internet rubber” meets the “real-world road.”
Regular artificial neural networks (ANNs) are typically implemented using a humongous quantity of multiply-accumulate (MAC) operations. These are typically used to implement things like convolutional neural networks (CNNs) for working with images and videos, deep neural networks (DNNs) for working with general data, and recurrent neural networks (RNNs) for working with sequential (time-series) data.
When it comes to implementing these types of ANN for use at the extreme edge, the least efficient option is to use a regular microcontroller unit (MCU). The next step up is to use a digital signal processor (DSP), which can be simplistically thought of as being an MCU augmented with MAC functionality. One more step up the ladder takes us to an MCU augmented with a neural processing unit (NPU). For simplicity, we can visualize the NPU as being implemented as a huge array of MACs. In this case, the NPU cannot run in standalone mode—instead, it needs the MCU to be running to manage everything, feed it data, and action any results.
Furthermore, regular NPUs are designed to accelerate traditional ANNs, and they rely on conventional digital computing paradigms and synchronized operations. These NPUs process data in a batch mode, performing matrix computations (e.g., matrix multiplication) on large datasets, which can be resource-intensive.
By comparison, “neuromorphic” refers to a type of computing architecture that’s inspired by the structure and functioning of the human brain. It seeks to emulate neural systems by mimicking the way biological neurons and synapses communicate and process information. These systems focus on event-based, asynchronous processing that mimics how neurons fire.
Neuromorphic networks are often referred to as spiking neural networks (SNNs) because they model neural behavior using “spikes” to convey information. Since they perform processing only when changes occur in their input, SNNs dramatically reduce power consumption and latency.
What about sparsity?” I hear you cry. That’s a good question. Have you been reading my earlier columns? One problem with regular ANNs is that they tend to process everything, even things that aren’t worth processing. If you are multiplying two numbers together and one is 0, for example, then you already know that the answer will be 0. In the context of AI/ML inferencing, a 0 will have no effect on the result (and a very low value will have minimal effect on the result). The idea behind sparsity is to weed out any unnecessary operations.
In fact, there are three kinds of sparsity. The first is related to the coefficients (weights) used by the network. A preprocessor can be used to root through the network, detecting any low value weights (whose effect will be insignificant), setting them to 0, and then pruning any 0 elements from the network. The second type of sparsity is similar, but it relates to the activation functions. Once again, these can be pruned by a preprocessor.
The third type of sparsity is data sparsity. Think 0s being fed into the ANN, which blindly computes these nonsensical values (silly ANN). Data sparsity isn’t something that can be handled by a preprocessor.
How sparse can data be? Well, this depends on the application, but data can be pretty darned sparse, let me tell you. Think of a camera pointing at a door in a wall. I wouldn’t be surprised to learn that, in many cases, nothing was happening 99% of the time. Suppose the camera is running at 30 frames per second (fps). A typical CNN will process every pixel in every frame in every second. That’s a lot of computation being performed, and a lot of energy being consumed, to no avail.
By comparison, a neuromorphic NPU is event-based, which means it does something (on the processing front) only when there’s something to be done. To put this another way, while regular NPUs can handle only one or both weight and activation types of sparsity, neuromorphic NPUs can support all three types, thereby dropping their power consumption to the floor.
The reason I’m bubbling over with all this info is that I was just chatting with Steve Brightfield, who is the Chief Marketing Officer (CMO) at brainchip. The folks at brainchip are in the business of providing digital neuromorphic processor IP in the form of register transfer level (RTL) that ASIC, ASSP, and SoC developers can incorporate into their designs.
In my previous columns, I waxed eloquently about brainchip’s Akida fabric, which mimics the working of the human brain to analyze only essential sensor inputs at the point of acquisition, “processing data with unparalleled performance, precision, and reduced power consumption,” as the chaps and chapesses at brainchip will modestly inform anyone who cannot get out of the way fast enough.
Well, Steve was brimming over with enthusiasm to tell me all about their new Akida Pico ultra-low-power IP core. Since this operates in the microwatt (μW) to milliwatt (mW) range, Akida Pico empowers devices at the extreme edge to perform at their best without sacrificing battery life.
Even better, the Akida Pico can either operate in standalone mode or it can serve as the co-processor to a higher-level processor. In standalone mode, the Akida Pico can operate independently, allowing devices to process audio and vital sign data with minimal power consumption. This is ideal for smart medical devices that monitor vital signs continuously or voice-activated systems that need to respond instantly. By comparison, when used as a co-processor, the Akida Pico can offload demanding AI tasks from the higher-level processor, thereby ensuring that applications run efficiently while conserving energy. This really is the ultimate always-on wake-up core.
Example use cases include medical vitals monitoring and alarms, speech wake-up words for automatic speech recognition (ASR) start-up, and audio noise reduction for outdoor/noisy environments for hearing aids, earbuds, smartphones, and virtual reality/augmented reality (VR/AR) headsets.
How big is this IP? Well, a base configuration without memory will require 150K logic gates and occupy 0.12mm2 die area at a 22nm process. Adding 50KB of SRAM will boost this to 0.18mm2 of die area at a 22nm process. I mean to say, “Seriously?” Less than a fifth of a square millimeter for always on AI that consumes only microwatts of power? Give me strength!
Do you want to hear something really exciting? You do? Well, do you remember my column, Look at Something, Ask a Question, Hear an Answer: Welcome to the Future? In that column, I discussed how the folks at Zinn Labs had developed an event-based gaze-tracking system for AI-enabled smart frames and mixed-reality systems. As a reminder, look at this video:
As we see (no pun intended), the user looks at something, asks a spoken question, and receives a spoken answer. This system features the GenX320 metavision sensor from Prophesee.
Why do we care about this? Well, the thing is that this sensor is event-based. Steve from brainchip was chatting with the guys and gals at Prophesee. They told him that they typically need to take the event-based data coming out of their camera and convert it into a frame-based format to be fed to a CNN.
Think about it. The chaps and chapesses at brainchip typically need to take frame-based data and convert it into events that can be fed to their Akida fabric.
So, rather than going event-based data (from the camera) to frame-based data, and then frame-based data to event-based data (to the Akida processor), the folks from Prophesee and brainchip can simply feed the event-based data from the camera directly to the event-based Akida processor, thereby cutting latency and power consumption to a minimum.
My head is still buzzing with ideas pertaining to the applications of—and the implications associated with—Akida’s neuromorphic fabric. What say you? Do you have any thoughts you’d care to share?
Taking the Size and Power of Extreme Edge AI/ML to the Extreme Minimum
Earlier this year, I penned a couple of columns under the umbrella title “Mind-Boggling Neuromorphic Brain Chips.” One of the first comments I received concerning these columns was short, sharp, an…
www.eejournal.com
November 21, 2024
Taking the Size and Power of Extreme Edge AI/ML to the Extreme Minimum
by Max MaxfieldEarlier this year, I penned a couple of columns under the umbrella title “Mind-Boggling Neuromorphic Brain Chips.” One of the first comments I received concerning these columns was short, sharp, and sweet, simply reading, “Also, Brain-Boggling.”
Arrrggghhh. How did I miss that? How could I not have used “Brain-Boggling Neuromorphic Brain Chips”? There was much gnashing of teeth and rending of garb that day, let me tell you.
The articles in question (see Part 1 and Part 2) were focused on the folks at brainchip, whose claim to fame is to be the world’s first commercial producer of neuromorphic IP.
Before we plunge headfirst into the fray with gusto and abandon (and aplomb, of course), let’s first remind ourselves as to what we mean by the “neuromorphic” moniker. Also, as part of setting the scene, let’s remind ourselves that we are focusing our attentions on implementing artificial intelligence (AI) and machine learning (ML) tasks at the extreme edge of the internet. For example, creating intelligent sensors at the point where the “internet rubber” meets the “real-world road.”
Regular artificial neural networks (ANNs) are typically implemented using a humongous quantity of multiply-accumulate (MAC) operations. These are typically used to implement things like convolutional neural networks (CNNs) for working with images and videos, deep neural networks (DNNs) for working with general data, and recurrent neural networks (RNNs) for working with sequential (time-series) data.
When it comes to implementing these types of ANN for use at the extreme edge, the least efficient option is to use a regular microcontroller unit (MCU). The next step up is to use a digital signal processor (DSP), which can be simplistically thought of as being an MCU augmented with MAC functionality. One more step up the ladder takes us to an MCU augmented with a neural processing unit (NPU). For simplicity, we can visualize the NPU as being implemented as a huge array of MACs. In this case, the NPU cannot run in standalone mode—instead, it needs the MCU to be running to manage everything, feed it data, and action any results.
Furthermore, regular NPUs are designed to accelerate traditional ANNs, and they rely on conventional digital computing paradigms and synchronized operations. These NPUs process data in a batch mode, performing matrix computations (e.g., matrix multiplication) on large datasets, which can be resource-intensive.
By comparison, “neuromorphic” refers to a type of computing architecture that’s inspired by the structure and functioning of the human brain. It seeks to emulate neural systems by mimicking the way biological neurons and synapses communicate and process information. These systems focus on event-based, asynchronous processing that mimics how neurons fire.
Neuromorphic networks are often referred to as spiking neural networks (SNNs) because they model neural behavior using “spikes” to convey information. Since they perform processing only when changes occur in their input, SNNs dramatically reduce power consumption and latency.
What about sparsity?” I hear you cry. That’s a good question. Have you been reading my earlier columns? One problem with regular ANNs is that they tend to process everything, even things that aren’t worth processing. If you are multiplying two numbers together and one is 0, for example, then you already know that the answer will be 0. In the context of AI/ML inferencing, a 0 will have no effect on the result (and a very low value will have minimal effect on the result). The idea behind sparsity is to weed out any unnecessary operations.
In fact, there are three kinds of sparsity. The first is related to the coefficients (weights) used by the network. A preprocessor can be used to root through the network, detecting any low value weights (whose effect will be insignificant), setting them to 0, and then pruning any 0 elements from the network. The second type of sparsity is similar, but it relates to the activation functions. Once again, these can be pruned by a preprocessor.
The third type of sparsity is data sparsity. Think 0s being fed into the ANN, which blindly computes these nonsensical values (silly ANN). Data sparsity isn’t something that can be handled by a preprocessor.
How sparse can data be? Well, this depends on the application, but data can be pretty darned sparse, let me tell you. Think of a camera pointing at a door in a wall. I wouldn’t be surprised to learn that, in many cases, nothing was happening 99% of the time. Suppose the camera is running at 30 frames per second (fps). A typical CNN will process every pixel in every frame in every second. That’s a lot of computation being performed, and a lot of energy being consumed, to no avail.
By comparison, a neuromorphic NPU is event-based, which means it does something (on the processing front) only when there’s something to be done. To put this another way, while regular NPUs can handle only one or both weight and activation types of sparsity, neuromorphic NPUs can support all three types, thereby dropping their power consumption to the floor.
The reason I’m bubbling over with all this info is that I was just chatting with Steve Brightfield, who is the Chief Marketing Officer (CMO) at brainchip. The folks at brainchip are in the business of providing digital neuromorphic processor IP in the form of register transfer level (RTL) that ASIC, ASSP, and SoC developers can incorporate into their designs.
In my previous columns, I waxed eloquently about brainchip’s Akida fabric, which mimics the working of the human brain to analyze only essential sensor inputs at the point of acquisition, “processing data with unparalleled performance, precision, and reduced power consumption,” as the chaps and chapesses at brainchip will modestly inform anyone who cannot get out of the way fast enough.
Well, Steve was brimming over with enthusiasm to tell me all about their new Akida Pico ultra-low-power IP core. Since this operates in the microwatt (μW) to milliwatt (mW) range, Akida Pico empowers devices at the extreme edge to perform at their best without sacrificing battery life.
Even better, the Akida Pico can either operate in standalone mode or it can serve as the co-processor to a higher-level processor. In standalone mode, the Akida Pico can operate independently, allowing devices to process audio and vital sign data with minimal power consumption. This is ideal for smart medical devices that monitor vital signs continuously or voice-activated systems that need to respond instantly. By comparison, when used as a co-processor, the Akida Pico can offload demanding AI tasks from the higher-level processor, thereby ensuring that applications run efficiently while conserving energy. This really is the ultimate always-on wake-up core.
Example use cases include medical vitals monitoring and alarms, speech wake-up words for automatic speech recognition (ASR) start-up, and audio noise reduction for outdoor/noisy environments for hearing aids, earbuds, smartphones, and virtual reality/augmented reality (VR/AR) headsets.
How big is this IP? Well, a base configuration without memory will require 150K logic gates and occupy 0.12mm2 die area at a 22nm process. Adding 50KB of SRAM will boost this to 0.18mm2 of die area at a 22nm process. I mean to say, “Seriously?” Less than a fifth of a square millimeter for always on AI that consumes only microwatts of power? Give me strength!
Do you want to hear something really exciting? You do? Well, do you remember my column, Look at Something, Ask a Question, Hear an Answer: Welcome to the Future? In that column, I discussed how the folks at Zinn Labs had developed an event-based gaze-tracking system for AI-enabled smart frames and mixed-reality systems. As a reminder, look at this video:
As we see (no pun intended), the user looks at something, asks a spoken question, and receives a spoken answer. This system features the GenX320 metavision sensor from Prophesee.
Why do we care about this? Well, the thing is that this sensor is event-based. Steve from brainchip was chatting with the guys and gals at Prophesee. They told him that they typically need to take the event-based data coming out of their camera and convert it into a frame-based format to be fed to a CNN.
Think about it. The chaps and chapesses at brainchip typically need to take frame-based data and convert it into events that can be fed to their Akida fabric.
So, rather than going event-based data (from the camera) to frame-based data, and then frame-based data to event-based data (to the Akida processor), the folks from Prophesee and brainchip can simply feed the event-based data from the camera directly to the event-based Akida processor, thereby cutting latency and power consumption to a minimum.
My head is still buzzing with ideas pertaining to the applications of—and the implications associated with—Akida’s neuromorphic fabric. What say you? Do you have any thoughts you’d care to share?
Last edited:
Frangipani
Regular
Maximas gratias tibi agimus, Max Maxfield!
Taking the Size and Power of Extreme Edge AI/ML to the Extreme Minimum
Earlier this year, I penned a couple of columns under the umbrella title “Mind-Boggling Neuromorphic Brain Chips.” One of the first comments I received concerning these columns was short, sharp, an…
November 21, 2024
Taking the Size and Power of Extreme Edge AI/ML to the Extreme Minimum
by Max Maxfield
Earlier this year, I penned a couple of columns under the umbrella title “Mind-Boggling Neuromorphic Brain Chips.” One of the first comments I received concerning these columns was short, sharp, and sweet, simply reading, “Also, Brain-Boggling.”
Arrrggghhh. How did I miss that? How could I not have used “Brain-Boggling Neuromorphic Brain Chips”? There was much gnashing of teeth and rending of garb that day, let me tell you.
The articles in question (see Part 1 and Part 2) were focused on the folks at brainchip, whose claim to fame is to be the world’s first commercial producer of neuromorphic IP.
Before we plunge headfirst into the fray with gusto and abandon (and aplomb, of course), let’s first remind ourselves as to what we mean by the “neuromorphic” moniker. Also, as part of setting the scene, let’s remind ourselves that we are focusing our attentions on implementing artificial intelligence (AI) and machine learning (ML) tasks at the extreme edge of the internet. For example, creating intelligent sensors at the point where the “internet rubber” meets the “real-world road.”
Regular artificial neural networks (ANNs) are typically implemented using a humongous quantity of multiply-accumulate (MAC) operations. These are typically used to implement things like convolutional neural networks (CNNs) for working with images and videos, deep neural networks (DNNs) for working with general data, and recurrent neural networks (RNNs) for working with sequential (time-series) data.
When it comes to implementing these types of ANN for use at the extreme edge, the least efficient option is to use a regular microcontroller unit (MCU). The next step up is to use a digital signal processor (DSP), which can be simplistically thought of as being an MCU augmented with MAC functionality. One more step up the ladder takes us to an MCU augmented with a neural processing unit (NPU). For simplicity, we can visualize the NPU as being implemented as a huge array of MACs. In this case, the NPU cannot run in standalone mode—instead, it needs the MCU to be running to manage everything, feed it data, and action any results.
Furthermore, regular NPUs are designed to accelerate traditional ANNs, and they rely on conventional digital computing paradigms and synchronized operations. These NPUs process data in a batch mode, performing matrix computations (e.g., matrix multiplication) on large datasets, which can be resource-intensive.
By comparison, “neuromorphic” refers to a type of computing architecture that’s inspired by the structure and functioning of the human brain. It seeks to emulate neural systems by mimicking the way biological neurons and synapses communicate and process information. These systems focus on event-based, asynchronous processing that mimics how neurons fire.
Neuromorphic networks are often referred to as spiking neural networks (SNNs) because they model neural behavior using “spikes” to convey information. Since they perform processing only when changes occur in their input, SNNs dramatically reduce power consumption and latency.
What about sparsity?” I hear you cry. That’s a good question. Have you been reading my earlier columns? One problem with regular ANNs is that they tend to process everything, even things that aren’t worth processing. If you are multiplying two numbers together and one is 0, for example, then you already know that the answer will be 0. In the context of AI/ML inferencing, a 0 will have no effect on the result (and a very low value will have minimal effect on the result). The idea behind sparsity is to weed out any unnecessary operations.
In fact, there are three kinds of sparsity. The first is related to the coefficients (weights) used by the network. A preprocessor can be used to root through the network, detecting any low value weights (whose effect will be insignificant), setting them to 0, and then pruning any 0 elements from the network. The second type of sparsity is similar, but it relates to the activation functions. Once again, these can be pruned by a preprocessor.
The third type of sparsity is data sparsity. Think 0s being fed into the ANN, which blindly computes these nonsensical values (silly ANN). Data sparsity isn’t something that can be handled by a preprocessor.
How sparse can data be? Well, this depends on the application, but data can be pretty darned sparse, let me tell you. Think of a camera pointing at a door in a wall. I wouldn’t be surprised to learn that, in many cases, nothing was happening 99% of the time. Suppose the camera is running at 30 frames per second (fps). A typical CNN will process every pixel in every frame in every second. That’s a lot of computation being performed, and a lot of energy being consumed, to no avail.
By comparison, a neuromorphic NPU is event-based, which means it does something (on the processing front) only when there’s something to be done. To put this another way, while regular NPUs can handle only one or both weight and activation types of sparsity, neuromorphic NPUs can support all three types, thereby dropping their power consumption to the floor.
The reason I’m bubbling over with all this info is that I was just chatting with Steve Brightfield, who is the Chief Marketing Officer (CMO) at brainchip. The folks at brainchip are in the business of providing digital neuromorphic processor IP in the form of register transfer level (RTL) that ASIC, ASSP, and SoC developers can incorporate into their designs.
In my previous columns, I waxed eloquently about brainchip’s Akida fabric, which mimics the working of the human brain to analyze only essential sensor inputs at the point of acquisition, “processing data with unparalleled performance, precision, and reduced power consumption,” as the chaps and chapesses at brainchip will modestly inform anyone who cannot get out of the way fast enough.
Well, Steve was brimming over with enthusiasm to tell me all about their new Akida Pico ultra-low-power IP core. Since this operates in the microwatt (μW) to milliwatt (mW) range, Akida Pico empowers devices at the extreme edge to perform at their best without sacrificing battery life.
Even better, the Akida Pico can either operate in standalone mode or it can serve as the co-processor to a higher-level processor. In standalone mode, the Akida Pico can operate independently, allowing devices to process audio and vital sign data with minimal power consumption. This is ideal for smart medical devices that monitor vital signs continuously or voice-activated systems that need to respond instantly. By comparison, when used as a co-processor, the Akida Pico can offload demanding AI tasks from the higher-level processor, thereby ensuring that applications run efficiently while conserving energy. This really is the ultimate always-on wake-up core.
Example use cases include medical vitals monitoring and alarms, speech wake-up words for automatic speech recognition (ASR) start-up, and audio noise reduction for outdoor/noisy environments for hearing aids, earbuds, smartphones, and virtual reality/augmented reality (VR/AR) headsets.
How big is this IP? Well, a base configuration without memory will require 150K logic gates and occupy 0.12mm2 die area at a 22nm process. Adding 50KB of SRAM will boost this to 0.18mm2 of die area at a 22nm process. I mean to say, “Seriously?” Less than a fifth of a square millimeter for always on AI that consumes only microwatts of power? Give me strength!
Do you want to hear something really exciting? You do? Well, do you remember my column, Look at Something, Ask a Question, Hear an Answer: Welcome to the Future? In that column, I discussed how the folks at Zinn Labs had developed an event-based gaze-tracking system for AI-enabled smart frames and mixed-reality systems. As a reminder, look at this video:
As we see (no pun intended), the user looks at something, asks a spoken question, and receives a spoken answer. This system features the GenX320 metavision sensor from Prophesee.
Why do we care about this? Well, the thing is that this sensor is event-based. Steve from brainchip was chatting with the guys and gals at Prophesee. They told him that they typically need to take the event-based data coming out of their camera and convert it into a frame-based format to be fed to a CNN.
Think about it. The chaps and chapesses at brainchip typically need to take frame-based data and convert it into events that can be fed to their Akida fabric.
So, rather than going event-based data (from the camera) to frame-based data, and then frame-based data to event-based data (to the Akida processor), the folks from Prophesee and brainchip can simply feed the event-based data from the camera directly to the event-based Akida processor, thereby cutting latency and power consumption to a minimum.
My head is still buzzing with ideas pertaining to the applications of—and the implications associated with—Akida’s neuromorphic fabric. What say you? Do you have any thoughts you’d care to share?
Only just watched the embedded video, as I got distracted from this winter’s first snowflakes dancing outside my window - so beautiful to behold…
Cracked up laughing during the above scene (from 1:15 min).
While the translation of the “Achtung!” sticker is correct, the smart glasses’ voice assistant’s pronunciation of the German original leaves MUCH to be desired!
Matsch!!!
Frangipani
Regular
Maximas gratias tibi agimus, Max Maxfield!
Taking the Size and Power of Extreme Edge AI/ML to the Extreme Minimum
Earlier this year, I penned a couple of columns under the umbrella title “Mind-Boggling Neuromorphic Brain Chips.” One of the first comments I received concerning these columns was short, sharp, an…
November 21, 2024
Taking the Size and Power of Extreme Edge AI/ML to the Extreme Minimum
by Max Maxfield
Earlier this year, I penned a couple of columns under the umbrella title “Mind-Boggling Neuromorphic Brain Chips.” One of the first comments I received concerning these columns was short, sharp, and sweet, simply reading, “Also, Brain-Boggling.”
Arrrggghhh. How did I miss that? How could I not have used “Brain-Boggling Neuromorphic Brain Chips”? There was much gnashing of teeth and rending of garb that day, let me tell you.
The articles in question (see Part 1 and Part 2) were focused on the folks at brainchip, whose claim to fame is to be the world’s first commercial producer of neuromorphic IP.
Before we plunge headfirst into the fray with gusto and abandon (and aplomb, of course), let’s first remind ourselves as to what we mean by the “neuromorphic” moniker. Also, as part of setting the scene, let’s remind ourselves that we are focusing our attentions on implementing artificial intelligence (AI) and machine learning (ML) tasks at the extreme edge of the internet. For example, creating intelligent sensors at the point where the “internet rubber” meets the “real-world road.”
Regular artificial neural networks (ANNs) are typically implemented using a humongous quantity of multiply-accumulate (MAC) operations. These are typically used to implement things like convolutional neural networks (CNNs) for working with images and videos, deep neural networks (DNNs) for working with general data, and recurrent neural networks (RNNs) for working with sequential (time-series) data.
When it comes to implementing these types of ANN for use at the extreme edge, the least efficient option is to use a regular microcontroller unit (MCU). The next step up is to use a digital signal processor (DSP), which can be simplistically thought of as being an MCU augmented with MAC functionality. One more step up the ladder takes us to an MCU augmented with a neural processing unit (NPU). For simplicity, we can visualize the NPU as being implemented as a huge array of MACs. In this case, the NPU cannot run in standalone mode—instead, it needs the MCU to be running to manage everything, feed it data, and action any results.
Furthermore, regular NPUs are designed to accelerate traditional ANNs, and they rely on conventional digital computing paradigms and synchronized operations. These NPUs process data in a batch mode, performing matrix computations (e.g., matrix multiplication) on large datasets, which can be resource-intensive.
By comparison, “neuromorphic” refers to a type of computing architecture that’s inspired by the structure and functioning of the human brain. It seeks to emulate neural systems by mimicking the way biological neurons and synapses communicate and process information. These systems focus on event-based, asynchronous processing that mimics how neurons fire.
Neuromorphic networks are often referred to as spiking neural networks (SNNs) because they model neural behavior using “spikes” to convey information. Since they perform processing only when changes occur in their input, SNNs dramatically reduce power consumption and latency.
What about sparsity?” I hear you cry. That’s a good question. Have you been reading my earlier columns? One problem with regular ANNs is that they tend to process everything, even things that aren’t worth processing. If you are multiplying two numbers together and one is 0, for example, then you already know that the answer will be 0. In the context of AI/ML inferencing, a 0 will have no effect on the result (and a very low value will have minimal effect on the result). The idea behind sparsity is to weed out any unnecessary operations.
In fact, there are three kinds of sparsity. The first is related to the coefficients (weights) used by the network. A preprocessor can be used to root through the network, detecting any low value weights (whose effect will be insignificant), setting them to 0, and then pruning any 0 elements from the network. The second type of sparsity is similar, but it relates to the activation functions. Once again, these can be pruned by a preprocessor.
The third type of sparsity is data sparsity. Think 0s being fed into the ANN, which blindly computes these nonsensical values (silly ANN). Data sparsity isn’t something that can be handled by a preprocessor.
How sparse can data be? Well, this depends on the application, but data can be pretty darned sparse, let me tell you. Think of a camera pointing at a door in a wall. I wouldn’t be surprised to learn that, in many cases, nothing was happening 99% of the time. Suppose the camera is running at 30 frames per second (fps). A typical CNN will process every pixel in every frame in every second. That’s a lot of computation being performed, and a lot of energy being consumed, to no avail.
By comparison, a neuromorphic NPU is event-based, which means it does something (on the processing front) only when there’s something to be done. To put this another way, while regular NPUs can handle only one or both weight and activation types of sparsity, neuromorphic NPUs can support all three types, thereby dropping their power consumption to the floor.
The reason I’m bubbling over with all this info is that I was just chatting with Steve Brightfield, who is the Chief Marketing Officer (CMO) at brainchip. The folks at brainchip are in the business of providing digital neuromorphic processor IP in the form of register transfer level (RTL) that ASIC, ASSP, and SoC developers can incorporate into their designs.
In my previous columns, I waxed eloquently about brainchip’s Akida fabric, which mimics the working of the human brain to analyze only essential sensor inputs at the point of acquisition, “processing data with unparalleled performance, precision, and reduced power consumption,” as the chaps and chapesses at brainchip will modestly inform anyone who cannot get out of the way fast enough.
Well, Steve was brimming over with enthusiasm to tell me all about their new Akida Pico ultra-low-power IP core. Since this operates in the microwatt (μW) to milliwatt (mW) range, Akida Pico empowers devices at the extreme edge to perform at their best without sacrificing battery life.
Even better, the Akida Pico can either operate in standalone mode or it can serve as the co-processor to a higher-level processor. In standalone mode, the Akida Pico can operate independently, allowing devices to process audio and vital sign data with minimal power consumption. This is ideal for smart medical devices that monitor vital signs continuously or voice-activated systems that need to respond instantly. By comparison, when used as a co-processor, the Akida Pico can offload demanding AI tasks from the higher-level processor, thereby ensuring that applications run efficiently while conserving energy. This really is the ultimate always-on wake-up core.
Example use cases include medical vitals monitoring and alarms, speech wake-up words for automatic speech recognition (ASR) start-up, and audio noise reduction for outdoor/noisy environments for hearing aids, earbuds, smartphones, and virtual reality/augmented reality (VR/AR) headsets.
How big is this IP? Well, a base configuration without memory will require 150K logic gates and occupy 0.12mm2 die area at a 22nm process. Adding 50KB of SRAM will boost this to 0.18mm2 of die area at a 22nm process. I mean to say, “Seriously?” Less than a fifth of a square millimeter for always on AI that consumes only microwatts of power? Give me strength!
Do you want to hear something really exciting? You do? Well, do you remember my column, Look at Something, Ask a Question, Hear an Answer: Welcome to the Future? In that column, I discussed how the folks at Zinn Labs had developed an event-based gaze-tracking system for AI-enabled smart frames and mixed-reality systems. As a reminder, look at this video:
As we see (no pun intended), the user looks at something, asks a spoken question, and receives a spoken answer. This system features the GenX320 metavision sensor from Prophesee.
Why do we care about this? Well, the thing is that this sensor is event-based. Steve from brainchip was chatting with the guys and gals at Prophesee. They told him that they typically need to take the event-based data coming out of their camera and convert it into a frame-based format to be fed to a CNN.
Think about it. The chaps and chapesses at brainchip typically need to take frame-based data and convert it into events that can be fed to their Akida fabric.
So, rather than going event-based data (from the camera) to frame-based data, and then frame-based data to event-based data (to the Akida processor), the folks from Prophesee and brainchip can simply feed the event-based data from the camera directly to the event-based Akida processor, thereby cutting latency and power consumption to a minimum.
My head is still buzzing with ideas pertaining to the applications of—and the implications associated with—Akida’s neuromorphic fabric. What say you? Do you have any thoughts you’d care to share?
Half an hour ago, the author also shared a link to his entertaining article
on LinkedIn:
CHIPS
Regular
It must be an older article because of this sentence:
Other processors that are likely to come out within the next couple of years, such as Zeroth, Akida etc., cater to edge applications.
Quiltman
Regular
Yep, I believe the LInkedIn post from TCS referred to the blog that was posted a couple of years ago.
Still the reference mentioned ... but a date stamp would be nice.
Why the new LinkedIn post then? Reminding us of their enthusiasm for all things neuromorphic ?
However, puts the "next couple of years" comments into a different frame doesn't it!
That would be about NOW then.
Similar threads
